High density D-sub connectors are available at SignalOrigin. SignalOrigin offers inventory, pricing, & datasheets for High density D-sub connectors. Our D-Sub connector portfolio is designed for multiple applications along with specialized accessories that will provide any customer with an economical d-sub solution for any complex application.

High density d sub connectors from SignalOrigin

The high density D-Sub range is part of SignalOrigin’s I/O connections portfolio that provides customers access to a wide range of industry standard and application specific I/O interconnect solutions. SignalOrigin’s I/O connector solutions complete board and system designs by providing high density, high-speed interfaces to enable interconnect technologies for networking, storage and memory, and complementary products for power distribution. The range of standardized I/O solutions enables full compliance to industry standards such as Ethernet, SFF, infiniband, USB, PCMCIA or HDMI. With SignalOrigin’s high-speed, power, assembly, and mechanical packaging expertise, a designer gains the advantage of getting his signals out of the box at optimal cost and performance.

High density D-sub connectors

Advantage of High density d sub connectors

  • High density d-sub is the answer to the increasing need for higher density packaging
  • Available with different PCB mounting and panel mounting accessory options
  • Selected layouts available in press fit and pin-in-paste versions
  • Contact layout: 15, 26, 44, 62, or 78 positions

Specifications of High density d sub connectors

  • Color:Can be customized
  • Connector Style:High density D-sub connectors
  • Dielectric rating: 300V
  • Contact current rating: 3 Amp
  • Contact resistance: 15 Ω Max
  • Insulation resistance: 1000M Ω Min. at 500V DC
  • Dielectric strength: 500V AC RMS for 1 Minute
  • Operation temperature: -55°C ~125°C
  • Insulator: PBT+30% G.F (UL94V-0)
  • Contact: Copper alloy
  • Contact plated: Gold finish over nickel
  • Shell: SPCC
  • Shell plated: Nickel/Tin

Image Description Number of position Connector type
High density d sub 15 pin male connector for sale High density d sub 15 pin male connector for sale 15 Right angle, male plug
 26 pin male 90 degree d sub connector 26 pin male 90 degree d sub connector 26 Right angle, male plug
 Standard angle D Sub 26 pin connector for sale Standard angle D Sub 26 pin connector for sale 26 Right angle, female socket
 right angle 26 pin d-sub connector manufacturer Right angle 26 pin d-sub connector manufacturer 26 Right angle, male plug
 44 pin female standard d sub connectors 44 pin female standard d sub connectors 44 Straight, male plug
62 pin female d sub standard connectors 62 pin female d sub standard connectors 62 Right angle, female socket
78 pin female righ angle high density d-sub connectors supplier 78 pin female right angle high density d-sub connectors supplier 78 Right angle, female socket
78 pin right angle pcb socket connector 78 pin right angle pcb socket connector 78 Right angle, female socket

You may also like What businesses does SIGNALORIGIN engage in?

If you’re interested in purchasing High density D-sub connectors, be sure to check out the wide range of standard and custom products from SIGNALORIGIN.
