25 pin male d sub connector with boardlocks

Home » Products » 25 pin male d sub connector with boardlocks

25 pin male d sub connector with boardlocks

  • 25 pin male d sub connector, high density

  • All contacts are machined copper alloy

  • High reliability

  • Bracket/screw:copper alloy material, Ni plated

Inquiry Now

Description

25 pin male d sub connector with boardlocks. These connectors are made of the highest quality materials to ensure maximum operational efficiency during high intensity and mission critical applications. This d sub connectors are suitable for military, industrial or commercial applications and computer interfacing etc. You may like 25 pin female d-sub connector.

Specification of 25 pin male d sub connector with boardlocks

P/N  XHY-06-009


25 pin male d sub connector with boardlocks

25 pin male d sub connector with boardlocks





PDF Drawing Download

     Material Insulator material PBT+30% G.F (UL94V-O)
Insulator color Black/Blue (can be customized)
Contacts material Copper Alloy
Contact plating Gold finish over nickel
Shell material Steel/SPCC-SD, nickel or tin plated
     Electrical Working voltage 300V AC
Current rating 5 AMP
Contacts OD ∮1.0
Contact resistance 15mΩ Max
Insulation resistance 1000MΩ Min at 500V DC
     Mechanical Dielectric strength 500V AC rms  at 1 minute
Insertion force ∮1.0 : 0.6~2 N /Pin
Extraction force ∮1.0: 0.3 N /Pin min
Durability 500 cycles
Operating temperature -55°C to +125°C

Drawing of 25 pin male d sub connector with boardlocks

25 pin male d sub connector with boardlocks
