15 pin dual-port right angle d-sub connector supplier

  • RoHS compliant

  • Industry standard compatibility

  • Comprehensive product size, and customization available

  • Short-term products delivery, normally 3~7 days

  • PDF Drawing Download

Inquiry Now

Description

SIGNALORIGIN is the 15 pin dual-port right angle d-sub connector supplier. Dual D-Sub where we can mix different types of D-Sub in a stacked layout,the limitations comes to the shell size, same shell size is to prefer when stacking two D-Sub connector on each other. Our D-Subminiature connector portfolio is designed for multiple applications along with specialized accessories that will provide any customer with an economical d-sub solution for any complex application.

SIGNALORIGIN’s D-sub connectors are ideally suited for applications such as Robotics & Automation, Machine Manufacturing, Agriculture & Construction Equipment, Energy, Communication, Military, Medical, Transportation.

Specification of 15 pin dual-port right angle d-sub connector supplier

P/N XHY-




15 pin dual-port right angle d-sub connector supplier

15 pin dual-port right angle d-sub connector supplier







PDF Drawing Download

     Material Insulator material PBT thermoplastic, UL94-V0 fireproof rated
Insulator color Black/Blue (can be customized)
Contacts material Phosphor Copper
Contact plating Gold Plated, 1U”-30U”
Shell material Steel/SPCC-SD, nickel or tin plated
     Electrical Working voltage 300V AC
High power contacts current rating 10A-40A(customized)
Signal contacts current rating 3A
Contact resistance 15mΩ Max
Insulation resistance 2000MΩ Min.at 500v DC
     Mechanical Dielectric withstanding voltage 1000V AC rms  at 1 minute
Insertion force ¢1.0 :0.6~2 N /Pin
¢3.6:2~7 N /Pin
Extraction force ¢1.0:0.2 N /Pin MIN
¢3.6:0.5 N /Pin MIN
Durability 500 cycles
Operating temperature -55°C to +125°C

Drawing of 15 pin dual-port right angle d-sub connector supplier

Solder cup waterproof female db 15 pin connector
