3V3 female d-sub coaxial power connector

  • Hight freqency contact: Phosphor copper material, gold plated

  • Insertable and removable power, high voltage and signal contacts

  • The power contacts are available with current rating ranging between 10A – 40A

  • Various quality d sub connectors classes are available

Inquiry Now

Description

3V3 female d-sub coaxial power connector, with gold over nickel plated phosphor copper alloy contacts and tin/nickel finish steel shell. This connector features thermoplastic type PCT UL94V-0 insulator. This connectors we can offer solder up, right angle and straight solder termination options and industrial performance. You may like 3v3 male d-sub connector.

Specification of 3V3 female d-sub coaxial power connector

P/N  XHY-05-0602


3V3 female d-sub coaxial power connector



PDF Drawing Download

     Material Insulator material PBT+30% G.F (UL94V-O)
Insulator color Black/Blue (can be customized)
Contacts material Phosphor copper
Contact plating Gold finish over nickel
Shell material Steel/SPCC-SD, nickel or tin plated
     Electrical Dielectric rating 300V AC
Current rating 3 AMP
Contacts OD ∮0.76
Contact resistance 15mΩ Max
Insulation resistance 1000MΩ Min at 500V DC
     Mechanical Dielectric withstanding voltage 750V AC rms  at 1 minute
Insertion force ∮0.76: 0.3~2N /Pin
Extraction force ∮0.76: 02 N /Pin min
Durability 500 cycles
Operating temperature -55°C to +125°C

Drawing of 3V3 female d-sub coaxial power connector
