37 pin d-sub male solder cup pcb connector

  • 37 pin d-sub male pcb connector, solder cup type

  • High density

  • All contacts are precision machined,Gold plating options available

  • Contact terminations can be Solder cup, Solder pin, Wire wrap

Inquiry Now

Description

37 pin d-sub male solder cup pcb connector. These solder style high density connectors conform to commercial industry standards and will mate with any opposite gender high density D-sub contact. Contact plating is gold flash, connector insulator is UL94V-0 rated. These connectors are ideal for high volume production. Offered in both solder and crimp versions these connectors are perfect for all of your cable termination needs. You may like 37 pin female d-sub connectors.

Specification of 37 pin d-sub male solder cup pcb connector

P/N XHY-06-0001


37 pin d-sub male solder cup pcb connector



PDF Drawing Download

     Material Insulator material PBT+30% G.F (UL94V-O)
Insulator color Black/Blue (can be customized)
Contacts material Copper Alloy
Contact plating Gold finish over nickel
Shell material Steel/SPCC-SD, nickel or tin plated
     Electrical Dielectric rating 300V AC
Current rating 5 AMP
Contacts OD ∮1.0
Contact resistance 15mΩ Max
Insulation resistance 1000MΩ Min at 500V DC
     Mechanical Dielectric withstanding voltage 500V AC rms  at 1 minute
Insertion force ∮1.0 : 0.6~2 N /Pin
Extraction force ∮1.0: 0.3 N /Pin min
Durability 500 cycles
Operating temperature -55°C to +105°C

Drawing of 37 pin d-sub male solder cup pcb connector

37 pin d-sub male solder cup pcb connector
