D sub female connector solder cup coaxial terminal wholesale

  • All coax contacts are precision machined

  • Coaxial contact impedance: 50Ω+/-5Ω;75Ω+/-5Ω

  • Dielectric withstanding voltace: 750v ac for 1 minute

  • All our contacts are RoHS & UL Compliant versions available

Inquiry Now

Description

D sub female connector solder cup coaxial terminal wholesale. This gold contact is made of gold over nickel plated phosphor alloy, high performance, precision machined contacts, solder cup standard mating types, the coaxial contact impedance is 50Ω+/-5Ω;75Ω+/-5Ω.

Specification of D sub female connector solder cup coaxial terminal wholesale

 P/N XHY-07-0017


d sub female connector solder cup coaxial terminal wholesale

PDF Drawing Download

Material Contacts material Brass
Contact Plating Gold Plated, 1U”-30U”
Contact insulator material TEFLON
Electrical Working Voltage 250V AC
Contact resistance 3mΩ
Coaxial contact impedance 50Ω;75Ω
The radio frequency range 0~4ghz.
Voltage standing wave ratio 1.3max
Insulation resistance 2000MΩ Min
Mechanical Dielectric Withstanding Voltage 750V AC rms  at 1 minute
Insertion force 2-7 N /Pin
Extraction force 0.5 N /Pin
Durability 500 cycles
Operating temperature -55°C to +125°C

Drawing of d sub female connector solder cup coaxial terminal wholesale

D sub female connector solder cup coaxial terminal wholesale
