SIGNALORIGIN Is A Trusted Manufacturer Of M16 5-pin Waterproof Solder Cup Circular Power Connectors, Designed For High-reliability Electrical Connections In Industrial And Outdoor Environments. These Connectors Support A Wide Range Of Voltages And Currents, With Excellent Sealing Performance (IP-rated) And Rugged Mechanical Durability, Making Them Ideal For Power Transmission In Automation, Energy, Transportation, And Communication Systems.
From Compact M12 To Large M58 Connectors, SIGNALORIGIN Offers A Complete Cable And Connector Solution—from The Device Interface To The PCB. Whether You Need To Connect Power, Signal, Or Data—or A Combination—our Circular Connectors Ensure Fast Installation, Stable Performance, And Long-term Operational Reliability.
SIGNALORIGIN Is A Trusted Manufacturer Of M16 5-pin Waterproof Solder Cup Circular Power Connectors, Designed For High-reliability Electrical Connections In Industrial And Outdoor Environments. These Connectors Support A Wide Range Of Voltages And Currents, With Excellent Sealing Performance (IP-rated) And Rugged Mechanical Durability, Making Them Ideal For Power Transmission In Automation, Energy, Transportation, And Communication Systems.
From Compact M12 To Large M58 Connectors, SIGNALORIGIN Offers A Complete Cable And Connector Solution—from The Device Interface To The PCB. Whether You Need To Connect Power, Signal, Or Data—or A Combination—our Circular Connectors Ensure Fast Installation, Stable Performance, And Long-term Operational Reliability.
| Material | Insulator material | Bakelite Black |
| Insulator color | Pantone 299U (can be customized) | |
| Contacts material | Copper Alloy, Silvery finished | |
| Contact plating | Silvery Plated, 1U” | |
| Shell material | Zinc alloy, Ni finished | |
| Nut | Copper alloy, Ni finished | |
| Electrical | Working voltage | 500V AC |
| High power contacts current rating | 10A (customized) | |
| Contact resistance | 10 MILLIOHMS MAX | |
| Insulation resistance | 2000MΩ Min.at 500v DC | |
| Mechanical | Dielectric withstanding voltage | 1500V AC rms at 1 minute |
| Insertion force | ￠1.0 :0.6～2 N /Pin
￠3.6:2～7 N /Pin |
|
| Extraction force | ￠1.0:0.2 N /Pin MIN
￠3.6:0.5 N /Pin MIN |
|
| Durability | 500 cycles | |
| Operating temperature | -40°C to +85°C |
