Signalorigin Is A Leading Manufacturer Of 7-Pin Male Waterproof Circular Connectors, Designed For Reliable Signal, Power, And Data Transmission In Harsh And Space-Constrained Environments. These Compact Connectors Feature Rugged Mechanical Performance, Ip-Rated Environmental Sealing, And Easy Plug-And-Play Operation, Making Them Ideal For Both Indoor And Outdoor Applications.
Our Waterproof Circular Connectors Are Widely Used In Industrial Automation, Robotics, Transportation Systems, Medical Devices, And Outdoor Electronics. With Versatile Contact Configurations, High Voltage And Current Tolerance, And The Ability To House Multiple Contact Types In One Unit, Signalorigin Connectors Deliver Customized, Space-Saving Cabling Solutions That Meet The Demands Of Modern, High-Performance Systems.
| Material | Insulator material | PBT 4130, UL94-V0 fireproof rated |
| Insulator color | Pantone 299U (can be customized) | |
| Contacts material | H62 | |
| Contact plating | Gold Plated, 1U” | |
| Shell material | Steel/SPCC-SD, nickel or tin plated | |
| Electrical | Working voltage | 120V AC |
| High power contacts current rating | 10A-40A(customized) | |
| Signal contacts current rating | 3A | |
| Contact resistance | 30mΩ Max | |
| Insulation resistance | 1000MΩ Min.at 500v DC | |
| Mechanical | Dielectric withstanding voltage | 750V AC rms at 1 minute |
| Insertion force | ￠1.0 :0.6～2 N /Pin
￠3.6:2～7 N /Pin |
|
| Extraction force | ￠1.0:0.2 N /Pin MIN
￠3.6:0.5 N /Pin MIN |
|
| Durability | 500 cycles | |
| Operating temperature | -40°C to +125°C |
